AYANEO

AYANEO Flip KB

A clamshell Windows handheld: 7-inch 1080p 120 Hz touchscreen on a hinge, a full RGB keyboard where the controls would sit on other handhelds, Ryzen 7 8840U, USB4 plus OCuLink, 45 Wh and 650 g.

Display
7″ 120 Hz IPS LCD
1920 × 1080
Chip
AMD Ryzen 7 8840U
8 / 16 cores / threads
About this chip →
Memory
16 GB / 32 GB / 64 GB
LPDDR5X
Battery
45 Wh
Weight
650 g
Compare with AYANEO 3Official spec sheet
1 / 2
1 / 2 · Image: AYANEO
AYANEO Flip KB open, front view in Shadow Black

AYANEO Flip KB open, front view in Shadow Black

Image: AYANEOChecked October 23, 2026

Models & list prices

Manufacturer list prices (MSRP), not retail offers.

ModelLaunch (USD)Current list (USD)
Ryzen 7 8840U / 16 GB / 512 GB$939[2]No change on file
Ryzen 7 8840U / 32 GB / 2 TB$1,169[2]No change on file
Ryzen 7 8840U / 64 GB / 2 TB$1,439[2]No change on file

Chip & performance

SpecificationValue
Chip (SoC)AMD Ryzen 7 8840U[1][4]AYANEO also sold a Ryzen 7 7840U version.
Process nodeTSMC 4nm FinFET[5]
CPUZen 4, 8 MB L2 / 16 MB L3[5]
CPU cores / threads8 / 16[5]
CPU clock3.3–5.1 GHz[5]
GPUAMD Radeon 780M[1]
GPU cores12 CUs[5]
GPU clock2.7 GHz[5]Chip maximum from the chip maker; the device may run lower.
Power range (TDP)15–30 W[5]AMD's configurable TDP range (default 28 W); the device sets its own limits.

Memory & storage

SpecificationValue
RAM16 GB / 32 GB / 64 GB[1]
RAM typeLPDDR5X[1]
RAM speed6400 MT/s[4]ReportedLPDDR5X-6400 in the 32 GB review unit; AYANEO does not publish the speed.
Storage512 GB / 2 TB[1][2]Store configurations are 512 GB and 2 TB.
Storage typeM.2 2230 PCIe 4.0 NVMe, up to 2 TB[1]
microSD slotYes[1]UHS-II TF slot, up to 300 MB/s

Display

SpecificationValue
Screen size7″[1]
Resolution1920 × 1080[1]
Refresh rate120 Hz[1]
PanelIPS LCD[1]
Peak brightness400 nits[1]100% sRGB coverage, 368 PPI
Variable refresh (VRR)Not published
HDRNot published
TouchscreenYes[4]Reported

Battery & build

SpecificationValue
Battery45 Wh[1]
Battery (mAh)Not published
ChargingNot published
Weight650 g[1]
Dimensions180 × 102 × 37.5 mm[1]AYANEO lists 180 × 102 × 29.8 mm, 37.5 mm at the grips, closed.

Connectivity & software

SpecificationValue
Wi-FiWi-Fi 6E[1]
BluetoothBluetooth 5.2[1]
Ports1× USB4 Type-C (40 Gbps) · 1× USB 3.2 Gen 2 Type-C (data only) · 1× OCuLink (SFF-8612) · UHS-II microSD slot · 3.5 mm headphone jack[1]
Operating systemWindows 11 Home (64-bit)[1]
ControlsFull RGB keyboard with Fn hotkeys · Optical finger mouse · Hall-sensing joysticks and linear Hall triggers · Six-axis gyroscope · X-axis linear motor · Fingerprint reader in the power button[1]

Sources

Each value above links to the source it was taken from. Last checked October 23, 2026. Spotted an error? Tell us.

  1. [1]AYANEO Flip KB specification · AYANEOmanufacturer · read October 23, 2026
  2. [2]AYANEO FLIP KB · AYANEO Storemanufacturer · read October 23, 2026
  3. [3]Ayaneo Flip Gaming Handheld Ships Soon With Full Keyboard Or Dual Screen Options · HotHardware, January 30, 2024news · read October 23, 2026
  4. [4]Ayaneo Flip KB review: handheld console with great functionality powered by the less efficient AMD Ryzen 7 8840U · Notebookcheck, December 2, 2024review · read October 23, 2026
  5. [5]AMD Ryzen 7 8840U specifications · AMDmanufacturer · read October 23, 2026
